Capacity
Capacity 384 TB maximum with expansion, depending on drive type
Standard number of drives supported
LFF chassis: 12 x LFF (3.5") drives
SFF chassis: 24 x SFF (2.5") drives
Maximum drives supported: 99 SFF drives or 48 LFF drives maximum including expansion
Storage expansion options: HP MSA 2040 LFF Disk Enclosure or D2700 SFF Disk Enclosure
Controller
Host interface
8 Gb Fibre Channel
1GbE iSCSI or 10GbE iSCSI
6/12 Gb SAS
(2 ports per controller)
Number of controllers: 2
RAID Support: 0, 1, 3, 5, 6, 10, 50
Cache Memory: 4GB Read/Write. ECC protection with backup to Flash memory (indefinite backup)
Disk Drive and Enclosure Protocol: 6 Gb SAS - Serial Attached SCSI
Expansion Port: SAS (SFF8088) 4x lane 6 Gb SAS
