*PCI-E
2 PCI-E 3.0 x16,
1 PCI-E 3.0 x8
*M.2
Interface: PCI-E 3.0 x4
Form Factor: 2242, 2280
Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SPM, SUM, SuperDoctor® 5, Watchdog, ACPI Power Management, Power-on mode for AC power recovery
-
Dual LAN with 1GbE with Marvell® 88E1512
Intel® C621 controller for 12 SATA3 (6 Gbps) ports; RAID 0,1,5,10
12x SATA3 (6Gbps) ports
Intel® C621 Chipset
Up to 192GB ECC RDIMM DDR4, up to 2666MHz; Up to 384GB ECC LRDIMM DDR4, Up to 768GB ECC 3DS LRDIMM DDR4 in 6x DIMM slots
Single Socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, CPU TDP support 165W
Aspeed AST2500 BMC
-
2x PCI-E 3.0 x16, 1x PCI-E 3.0 x8 (in x8)
-
