Processor: Dual Socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, CPU TDP support 205W, 2 UPI up to 10.4 GT/s, CPU1: Skylake-F CPU supported
Memory: Up to 2TB ECC RDIMM DDR4, up to 2666MHz; Up to 2TB ECC LRDIMM DDR4 in 16x DIMM slots
Hard Drive: 14x SATA3 (6Gbps) ports
Raid Controller: RAIDs 0, 1, 5, 10
Ethernet: Dual LAN with GbE from C621
Expansion slots: 4x PCI-E 3.0 x16, 2x PCI-E 3.0 x8, M.2 Interface: PCI-E 3.0 x4, M.2 Form Factor: 2260, 2280, 22110, 2x PCI-E 3.0 NVMExpress x4 Internal Port(s)
Dual Socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, CPU TDP support 205W, 2 UPI up to 10.4 GT/s, CPU1: Skylake-F CPU supported
4x PCI-E 3.0 x16, 2x PCI-E 3.0 x8, M.2 Interface: PCI-E 3.0 x4, M.2 Form Factor: 2260, 2280, 22110, 2x PCI-E 3.0 NVMExpress x4 Internal Port(s)
Intel® C621
Up to 2TB ECC RDIMM DDR4, up to 2666MHz; Up to 2TB ECC LRDIMM DDR4 in 16x DIMM slots
14x SATA3 (6Gbps) ports
Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, SPM, SSM, SUM, SuperDoctor® 5, Watchdog
-
Intel® C621 controller for 14 SATA3 (6 Gbps) ports; RAID 0,1,5,10
-
Dual LAN with GbE from C621
Aspeed AST2500 BMC
-
