Processor: Dual Socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, CPU TDP support 205W, 2 UPI up to 10.4 GT/s.CPU1: Skylake-F CPU supported, CPU2: Skylake-F CPU supported
Memory: Up to 2TB ECC RDIMM DDR4, up to 2666MHz; Up to 2TB ECC LRDIMM DDR4 in 16x DIMM slots
Hard Drive: 10x SATA3 (6Gbps) ports
Raid Controller: RAIDs 0, 1, 5, 10
Ethernet: Dual LAN with Intel® X550 10GBase-T Ethernet Controller
Expansion slots: 6x PCI-E 3.0 x16, 1x PCI-E 3.0 x4 (in x8 slot), M.2 Interface: PCI-E 3.0 x4, M.2 Form Factor: 22110
Audio: 7.1 HD Audio with optical S/PDIF, Thunderbolt AOC support
Aspeed AST2500 BMC
6x PCI-E 3.0 x16, 1x PCI-E 3.0 x4 (in x8 slot), M.2 Interface: PCI-E 3.0 x4, M.2 Form Factor: 22110
Intel® C621
Dual Socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, CPU TDP support 205W, 2 UPI up to 10.4 GT/s.CPU1: Skylake-F CPU supported, CPU2: Skylake-F CPU supported
Up to 2TB ECC RDIMM DDR4, up to 2666MHz; Up to 2TB ECC LRDIMM DDR4 in 16x DIMM slots
Intel® C621 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
-
10x SATA3 (6Gbps) ports
Dual LAN with Intel® X550 10GBase-T Ethernet Controller
-
Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SPM, SSM, SUM, SuperDoctor® 5, Watchdog, ACPI Power Management
7.1 HD Audio Header
